Specifications

Description of Technology

External wall:
Wall thickness = 23,5 cm

1. Gypsum fiber board FERMACELL 12.5 mm

2. Vapor barrier

3. KVH wood C24 KVH 60 x 160

4. Mineral wool - Rockwoll Rocton 3x50 mm

5. FERMACELL board 12.5 mm

6. Two glass windows with 6 chambers – Aluplast Ideal 4000 NEW

7. 50 mm of Styrofoam

8. Roughcast K 1,5

Heat transfer coefficient of external walls with 50 mm of Styrofoam is U = 0.18 W/m2K. This considerably reduces the heating cost of the house.

Prefabricated construction of the Bungalow

1. Topsoil
2. Substructure sand
3. Styrodur XPS F50
4. Building foil vapor barrier
5. Ribbed steel
6. Styrofoam EPS
7. Concrete B20
8. Trelleborg seal
9. KVH wood
10. Wool insulation

11. Vapor barrier
12. Fermacell board
13. Styrofoam 50 mm
14. Acrylic plaster
15. Exterior window sills
16. Windows
17. Soffit
18. OSB board (option)
19. Battens and counter battens
20. Roof foil

21. Steel tile
22. Chimney (option)
23. Reinforcement (option)
24. Siding (option)
25. Floor heating (option)
26. Radiator
27. Water installation
28. Sewer installation
29. Electric installation

Prefabricated construction of the building with 1st floor

1. Topsoil
2. Substructure sand
3. Styrodur XPS F50
4. Building foil vapor barrier
5. Ribbed steel
6. Styrofoam EPS
7. Concrete B20
8. Trelleborg seal
9. KVH wood
10. Wool insulation

11. Vapor barrier
12. Fermacell board
13. Styrofoam 50 mm
14. Acrylic plaster
15. Exterior window sills
16. Windows
18. OSB board
19. Trusses
20. Battens and counter battens
